FINECO's tsa pem teb panels rau chaw ua hauj lwm yog tsim tshwj xeeb rau cov niaj hnub chaw, muab zoo kawg li durability, yooj yim cable tswj, thiab exceptional load- bearing peev xwm. Lub modular xwm ntawm tus tsim enables ceev installation thiab adaptability rau reconfiguration. Nruab nrog tiv thaiv- zoo li qub thiab hluav taws kub- cov khoom tiv thaiv, lawv ua kom muaj kev nyab xeeb thiab zoo- chaw teeb tsa. Txawm hais tias nyob rau hauv cov chaw zov me nyuam, chaw ua haujlwm, lossis cov chaw lag luam, cov vaj huam sib luag no txhawb kev ua haujlwm zoo thiab zoo nkauj, muab cov kev daws teeb meem ruaj khov.
Khoom specification
|
Qauv |
Concentrated Load |
Impact Load |
Qhov kawg Load |
Uniform Load |
Rolling Load (N) |
||
|
LB |
N |
N |
N |
N/㎡ |
10x ua |
10000 zaug |
|
|
FS 800 Nws |
800 |
3560 |
536 |
10680 |
16100 |
3560 |
2670 |
|
FS1000 Nws |
1000 |
4450 |
670 |
13350 |
23000 |
4450 |
3560 |
|
TIAB SA 1250 |
1250 |
5560 |
780 |
16680 |
33000 |
5560 |
4450 |
|
FS1500 Nws |
1500 |
6660 |
1005 |
19980 |
34500 |
6675 |
5340 |
|
FS2000 Nws |
2000 |
8900 |
1340 |
26700 |
46000 |
8900 |
7120 |
* Raws li CE & CISCA cov txheej txheem kuaj pom zoo rau Access Floors
600 * 600mm / 24' * 24' (610 * 610mm) muaj
Khoom feature thiab daim ntawv thov
FINECO's tsa pem teb vaj huam sib luag rau chaw ua hauj lwm muab cov kev daws teeb meem thiab kev cia siab rau cov kev xav tau ntawm cov chaw ua haujlwm niaj hnub no. Ua los ntawm siab- zog, tiv thaiv- xeb hlau thiab coated nrog hluav taws kub- cov ntaub ntawv tiv taus, cov vaj huam sib luag no muab cov khoom zoo kawg nkaus - cov kabmob muaj peev xwm thiab kev ua haujlwm ruaj khov. Cov qauv tsim qauv ua kom yooj yim rau kev teeb tsa, tsis siv zog rov ua dua tshiab, thiab kev nkag mus tau yooj yim rau cov khoom siv hauv qab, txhawb kev ua haujlwm zoo. Ua- hauv kev tswj cov kab hluav taws xob ua kom zoo tshaj plaws hauv huab cua thiab ua tib zoo teeb tsa lub zog / cov ntaub ntawv cables, txo cov clutter. Qhov zoo tshaj plaws rau kev xav tau cov chaw xws li cov chaw zov me nyuam, cov chaw tsim khoom, cov chav tswj kev tswj hwm, thiab cov chaw soj nstuam, steel tsa pem teb lav kev nyab xeeb, yoog raws, thiab ua raws li cov qauv thoob ntiaj teb, catering rau dynamic spatial yuav tsum nrog kev saib xyuas tsawg.
Product details
FINECO's tsa pem teb panels rau chaw ua hauj lwm yog txawv los ntawm lawv precision -engineered cov ntsiab lus rau kev ua tau zoo. ESD ntug trims kom ntseeg tau tias tsis muaj qhov tsis zoo thiab ua kom zoo li qub thoob plaws hauv pem teb tag nrho. Txhua lub vaj huam sib luag yog raug rau cov hmoov epoxy nruj-coated los tiv thaiv- xeb, lav tiv thaiv corrosion nyob rau hauv qhov chaw ntub lossis hnyav. Ntau yam kev tiv thaiv kev tiv thaiv - cov kev xaiv laminate zoo li qub (HPL, PVC, ceramic) muab kev zoo nkauj kho kom zoo nkauj thaum tuav 10^4–10^9Ω nto kuj. Reinforced bolted stringers txhawb cov qauv kev ruaj ntseg, txhawb nqa taw tes loads txog 890kg. Hluav taws kub-rated cores ua raws li ASTM E84 Class 1 cov qauv. Optional gasket-cov npoo kaw ua rau huab cua- nruj compartments rau chav huv huv los yog cov ntawv siv siab, qhia txog cov panels 'versatility nyob rau hauv kev specifications.
Cov khoom tsim nyog
FINECO's tsa pem teb vaj huam sib luag rau chaw ua hauj lwm yog tsim los rau cov qauv nruj tshaj plaws thiab durability. Qhov no yog ua tiav los ntawm kev siv cov khoom zoo thiab cov txheej txheem tsim khoom. Cov khoom tseem ceeb yog tsim los ntawm qib siab -qib ST14 thiab SPCC steels, uas tau ua kev zoo siab rau lawv lub zog zoo kawg li, tiv thaiv corrosion, thiab formability. Yog li ntawd, cov vaj huam sib luag tuaj yeem tswj hwm lawv cov qauv kev ntseeg siab nyob rau hauv lub ntsej muag ntawm kev xav tau chaw ua haujlwm.
Lub teeb yuag ua npuas ncauj yog sib xyaw ua ke los txhim kho kev ua haujlwm. Nws txo qhov hnyav tag nrho thiab muab cov rwb thaiv tsev zoo heev, lub suab nqus, thiab eco- cov yam ntxwv zoo. Cov txheej txheem tsim khoom siv cov khoom ruaj khov, siab -tonnage presses. Cov xovxwm no ua kom lub siab sib xws thiab ua tib zoo shaping, tshem tawm cov khoom tsis xws luag thiab lav qhov tseeb qhov tseeb.
Kev sib koom ua ke ntawm cov ntaub ntawv zoo tshaj thiab kev lag luam- cov khoom siv qib theem coj los ntawm cov khoom lag luam uas tsis tu ncua kev lag luam cov qauv ntsuas ntawm kev ua haujlwm ntev, kev cia siab, thiab kev ua haujlwm zoo, hais txog cov neeg siv khoom xav tau nruj tshaj plaws.
Shipping thiab pob
FAQ
Q: 1.Dab tsi yog qhov sib txawv ntawm ib lub rooj zaum hauv pem teb rau chaw ua haujlwm thiab hauv pem teb tsis tu ncua?
A: Tus cwj pwm tseem ceeb ntawm cov vaj huam sib luag hauv pem teb rau cov chaw ua haujlwm yog lawv cov kev tsim kho siab, tsim kom muaj chaw ntxiv rau kev tswj hwm cable thiab cov koom haum khoom siv. Lawv kuj muaj cov tshuaj tiv thaiv- zoo li qub, hluav taws kub- tiv taus, thiab thauj khoom- cov kabmob zoo. Hauv qhov sib piv, cov plag tsev niaj hnub ntsia ncaj qha rau hauv av tsis muaj cov txiaj ntsig zoo.
Q: 2.Qhov twg yog tsa pem teb panels rau chaw ua hauj lwm feem ntau siv?
A: Cov vaj huam sib luag hauv pem teb rau cov chaw ua haujlwm tau siv dav hauv cov chaw khaws ntaub ntawv, chav computer, chav kuaj, chav tsev kho mob, chaw ua haujlwm, thiab lwm qhov chaw uas hu rau kev tswj hwm cable zoo thiab kev tswj ib puag ncig.
Q: 3. Ntev npaum li cas cov vaj huam sib luag hauv pem teb rau kev teeb tsa chaw ua haujlwm siv sijhawm?
A: Lub sijhawm xav tau rau kev teeb tsa nws txawv nrog qhov loj thiab qhov nyuaj ntawm thaj chaw. Cov chaw me me tuaj yeem ua tiav hauv hnub, tab sis cov ntaub ntawv loj loj yuav xav tau ntau lub lis piam. Kev npaj thiab ua haujlwm hauv kev sib koom tes nrog HVAC thiab pab pawg hluav taws xob yog qhov tseem ceeb.
Q: 4. Kuv puas tuaj yeem nruab ib lub rooj zaum hauv pem teb rau chaw ua haujlwm rau kuv tus kheej?
A: DIY installation tuaj yeem txiav txim siab rau cov txheej txheem tsim, tab sis rau cov haujlwm nyuaj, nrhiav kev txhim kho yog pom zoo. Kev sib dhos tsis raug yuav ua rau muaj kev ncaj ncees ntawm cov qauv, kev tswj xyuas cable, lossis kev nyab xeeb ntawm kev pheej hmoo.
Q: 5.Can tsa pem teb panels rau chaw ua hauj lwm disassembled thiab hloov los ntawm tus kheej?
A: Thaum tsa cov vaj huam sib luag rau cov chaw ua haujlwm tau tsim los ua cov qauv uas tuaj yeem tshem tawm, thiab ib tus tuaj yeem cuam tshuam thiab hloov lawv ntawm nws tus kheej, nws raug pom zoo kom cov neeg ua haujlwm tshaj lij ua haujlwm los lav kev nyab xeeb thiab ua haujlwm tau zoo.
